PVC Covered Solid Circular Copper Conductors

An image of the Wallis pvc covered solid circular copper conductor

Wallis PVC covered 8mm diameter copper conductors are mainly used as down conductors on a building’s structural lightning protection system.

There is a choice of five standard PVC colours to match the most common building materials and provide an aesthetic finish to the external lightning protection system. All the PVC coverings are UV stabilised although some discolouration may occur over time.

Other PVC colours are available to order but may be subject to minimum order quantities and lead-times. Please contact our sales office for further information.

D (mm)ColourC.S.A. (sqmm)D1 (mm)Weight per Metre (kg)Standard Coil Size (M)Part Number
D (mm)8ColourBrownC.S.A. (sqmm)50.27D1 (mm)10Weight per Metre (kg)0.49Standard Coil Size (M)50Part NumberCPC 08 B
D (mm)8ColourBlackC.S.A. (sqmm)50.27D1 (mm)10Weight per Metre (kg)0.49Standard Coil Size (M)50Part NumberCPC 08 BL
D (mm)8ColourGreyC.S.A. (sqmm)50.27D1 (mm)10Weight per Metre (kg)0.49Standard Coil Size (M)50Part NumberCPC 08 G
D (mm)8ColourStoneC.S.A. (sqmm)50.27D1 (mm)10Weight per Metre (kg)0.49Standard Coil Size (M)50Part NumberCPC 08 S
D (mm)8ColourWhiteC.S.A. (sqmm)50.27D1 (mm)10Weight per Metre (kg)0.49Standard Coil Size (M)50Part NumberCPC 08 W

Material: Copper to BS EN 13601 (formerly BS 1432).

PVC colours to BS 5252.
