Earth Bonding Points with Pre-welded Tails

In-situ image of a earth bonding point with a pre welded tail clamped to rebar

Dimensional drawing of a earth bonding point with a pre welded tail

These Wallis earth bonding points are installed to provide a convenient earth system connection point in concrete structures. When cast into concrete they connect the rebar to the earthing or lightning protection system.

No. Holes	Type	Unit Weight (kg)	Part Number
No. Holes1	TypeEGP 01 with pre-welded 500mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)0.52	Part NumberEGP 01 500	Quantity
No. Holes2	TypeEGP 02 with pre-welded 500mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)0.77	Part NumberEGP 02 500	Quantity
No. Holes2	TypeEGP 02 with pre-welded 1000mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)1.14	Part NumberEGP 02 1000	Quantity
No. Holes2	TypeEGP 02 with pre-welded 1500mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)1.50	Part NumberEGP 02 1500	Quantity
No. Holes4	TypeEGP 04 with pre-welded 500mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)1.02	Part NumberEGP 04 500	Quantity
No. Holes4	TypeEGP 04 with pre-welded 1000mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)1.39	Part NumberEGP 04 1000	Quantity
No. Holes4	TypeEGP 04 with pre-welded 1500mm long tail of 70sqmm PVC insulated cable	Unit Weight (kg)1.75	Part NumberEGP 04 1500	Quantity

Material: High Copper Alloy with PVC Insulated Copper Cable Tail.

Tested: BS EN 62561-1 Class H

Tightening Torque: 20 Nm
