Stainless Steel Lattice Mats

In-situ image of a solid copper lattice mat installed in the ground with a copper tape connection

Dimensional drawing of a solid copper lattice mat

Stainless Steel Lattice Mats, manufactured from Stainless Steel 316 grade are used in areas where a high corrosive environment is present.

They are often used for potential grading and are a preferred option on installations such as telecommunication towers, where touch and step potential could cause problems.

L x W (mm)	H (mm)	Surface Area sqm	Grid	Unit Weight (kg)	Pack Quantity	Part Number
L x W (mm)600 x 600	H (mm)3.0	Surface Area sqm0.31	Grid5 Bar	Unit Weight (kg)6.10	Pack Quantity1	Part NumberEML 603SS	Quantity
L x W (mm)600 x 600	H (mm)3.0	Surface Area sqm0.55	Grid10 Bar	Unit Weight (kg)	Pack Quantity1	Part NumberEML 603SS/10	Quantity
L x W (mm)900 x 900	H (mm)3.0	Surface Area sqm0.65	Grid6 Bar	Unit Weight (kg)7.30	Pack Quantity1	Part NumberEML 903SS	Quantity
L x W (mm)900 x 900	H (mm)3.0	Surface Area sqm0.89	Grid10 Bar	Unit Weight (kg)	Pack Quantity1	Part NumberEML 903SS/10	Quantity
L x W (mm)900 x 900	H (mm)5.0	Surface Area sqm0.56	Grid6 Bar	Unit Weight (kg)	Pack Quantity1	Part NumberEML 905SS	Quantity

Material: Stainless Steel to SS316 Grade and SS316 Rivets.
