Taper Pointed Air Rods

In-situ image of a taper pointed air rod connected to a flat air rod saddle with copper tape also shownDimensional drawing of a taper pointed air rod

Air rods form an important part of the air termination network of a lightning protection system. All of our air rods are supplied with a locknut enabling the rod to be locked tight against the conductor.

TypeThread SizeL (mm)L1 (mm)Unit Weight (kg)Pack QuantityPart Number
TypeCopper Air RodThread SizeM16L (mm)300L1 (mm)41Unit Weight (kg)0.53Pack Quantity5Part NumberATC 112M
TypeCopper Air RodThread SizeM16L (mm)500L1 (mm)41Unit Weight (kg)0.85Pack Quantity5Part NumberATC 120M
TypeCopper Air RodThread SizeM16L (mm)600L1 (mm)41Unit Weight (kg)1.00Pack Quantity5Part NumberATC 124M
TypeCopper Air RodThread SizeM16L (mm)1000L1 (mm)41Unit Weight (kg)1.70Pack Quantity5Part NumberATC 139M
TypeCopper Air RodThread SizeM16L (mm)1500L1 (mm)41Unit Weight (kg)2.59Pack Quantity5Part NumberATC 160M
TypeCopper Air RodThread SizeM16L (mm)2000L1 (mm)41Unit Weight (kg)3.47Pack Quantity5Part NumberATC 179M
TypeCopper Air RodThread SizeM16L (mm)3000L1 (mm)41Unit Weight (kg)5.10Pack Quantity5Part NumberATC 192M
TypeCopper Air RodThread SizeM20L (mm)300L1 (mm)41Unit Weight (kg)0.80Pack Quantity5Part NumberATC 212M
TypeCopper Air RodThread SizeM20L (mm)500L1 (mm)41Unit Weight (kg)1.34Pack Quantity5Part NumberATC 220M
TypeCopper Air RodThread SizeM20L (mm)1000L1 (mm)41Unit Weight (kg)2.68Pack Quantity5Part NumberATC 239M
TypeCopper Air RodThread SizeM20L (mm)1500L1 (mm)41Unit Weight (kg)4.02Pack Quantity5Part NumberATC 260M
TypeCopper Air RodThread SizeM20L (mm)2000L1 (mm)41Unit Weight (kg)5.36Pack Quantity5Part NumberATC 279M
TypeCopper Air RodThread SizeM20L (mm)3000L1 (mm)41Unit Weight (kg)8.04Pack Quantity5Part NumberATC 292M
TypeAluminium Air RodThread SizeM16L (mm)300L1 (mm)41Unit Weight (kg)0.18Pack Quantity5Part NumberATA 112M
TypeAluminium Air RodThread SizeM16L (mm)500L1 (mm)41Unit Weight (kg)0.29Pack Quantity5Part NumberATA 120M
TypeAluminium Air RodThread SizeM16L (mm)1000L1 (mm)41Unit Weight (kg)0.57Pack Quantity5Part NumberATA 139M
TypeAluminium Air RodThread SizeM16L (mm)1500L1 (mm)41Unit Weight (kg)0.98Pack Quantity5Part NumberATA 160M
TypeAluminium Air RodThread SizeM16L (mm)2000L1 (mm)41Unit Weight (kg)1.09Pack Quantity5Part NumberATA 179M

Material: (ATC) High Copper Alloy, (ATA) Aluminium

Tested: BS EN 62561-2
