Bimetallic Connectors

An image of 2 Wallis bimetallic connectors for 8mm solid circular conductors

The Wallis bimetallic connectors are used to join 8mm aluminium and copper solid circular conductors together. They are a neat and practical jointing method without the need for tinning, riveting or wrapping the joint.

Conductor Size (mm)Material TypeL (mm)W (mm)H (mm)Unit Weight (kg)Part Number
Conductor Size (mm)8Material TypeAluminium & CopperL (mm)78W (mm)28H (mm)28Unit Weight (kg)0.25Part NumberBIM 08
Conductor Size (mm)8Material TypeStainless SteelL (mm)71W (mm)22H (mm)19Unit Weight (kg)0.09Part NumberBSS 08
Conductor Size (mm)8 to 25 x 3Material TypeAluminium & CopperL (mm)78W (mm)28H (mm)29Unit Weight (kg)0.20Part NumberBIM 25308
Conductor Size (mm)8 to 25 x 3Material TypeStainless SteelL (mm)73W (mm)32H (mm)15Unit Weight (kg)0.13Part NumberBSS 25308

Tested: BS EN 62561-1 Class H
