WSP/TLP1/PRI

The WSP-TLP1-PRI Wallis data line surge protector

The WSP/TLP1/PRI is designed to protect 1 telephone circuit (pair). Suitable for use at LPZ0-1 according to BS EN 62305. This device protects connected equipment from the effects of common and differential mode surges, according to IEC 61643-21.

Features and Benefits:

  • Simple to install.
  • Response time (tA) <30ns.
  • Operating temperature -40oC to +80oC.
Nominal Voltage (Un)Max. Continuous Operating Voltage (Uc)Nominal Current (In)Nominal Discharge Current (8/20μs) (In)Voltage Protection Level at In (Up)Voltage Protection Level at 1kV/μsPart Number
Nominal Voltage (Un)170VMax. Continuous Operating Voltage (Uc)204VNominal Current (In)0.1ANominal Discharge Current (8/20μs) (In)1kAVoltage Protection Level at In (Up)500VVoltage Protection Level at 1kV/μs260VPart NumberWSP/TLP1/PRI

.
