WSP1M/6/230N (Mains, Type 2)

The WSP1M-6-230N Wallis mains distribution protection surge protector
Wiring diagram of a WSP1M-6-230N mains distribution surge protector

Single Phase Type 2 and 3 tested (BS EN 61643) modular surge protector for use primarily on mains power distribution systems to protect connected equipment from transient overvoltages. For use at the boundaries of LPZ 0b to LPZ 3 as part of a coordinated SPD system (BS EN 62305).

Features and Benefits:

  • 1, 2, 3 or 4 modular DIN rail mount connection bases.
  • 40kA MOV (Type 2) and 6 kA SAD (Type 2 and 3) plug-in protection modules.
  • Protection status indication.
  • Thermal disconnect for safe disconnection from abnormal or faulty supplies.
Nominal VOperating V RangeNominal Surge Current 8/20μsMax. Surge Current 8/20μsLet-through VLocationPart Number
Nominal V240Operating V Range200-300Nominal Surge Current 8/20μs3kA (L-N); 20kA (N-E)Max. Surge Current 8/20μs6kA (L-N); 40kA (N-E)Let-through V<500V @ In (L-N); <1.3kV @ In (N-E)LocationLPZ 1-2Part NumberWSP1M/6/230N

Tested: BS EN 61643-11
