WSP230S

The WSP230S is a class 3 surge arrester that offers a flexible solution to protecting individual pieces of equipment. Perfectly suited to protecting ring mains & individual sockets, switch fuse spurs, lighting, fire alarm panels, CCTV cameras etc.

Its small size means that it can be mounted in confined spaces and the audible alarm will indicate if the arrester needs to be replaced.

The WSP230S will offer up to 10 metres of protection either side of the device it is installed on.

Features and Benefits:

Simple to install.
A response time (^t_A) <25 ns.
Operating temperature between -25^oC – +70^oC.

Nominal A.C. Voltage (Un)	Max. Continuous Operating A. C. Voltage (Uc)	Nominal Discharge Current (8/20 μs) (In)	Total Discharge Current (8/20 μs) (L+N-PE) (Itotal)	Temporary Overvoltage (L-N) (Ut)	Temporary Overvoltage (L/N-PE) (Ut)	Temporary Overvoltage (L+N-PE) (Ut)	Part Number
Nominal A.C. Voltage (Un)230 V	Max. Continuous Operating A. C. Voltage (Uc)250 V	Nominal Discharge Current (8/20 μs) (In)1.5kA	Total Discharge Current (8/20 μs) (L+N-PE) (Itotal)3kA	Temporary Overvoltage (L-N) (Ut)335V/5 sec	Temporary Overvoltage (L/N-PE) (Ut)400V/5 sec	Temporary Overvoltage (L+N-PE) (Ut)1200V + Ucs / 200ms	Part NumberWSP230S	Quantity
