WSP-T2PV2/40/1000

The WSP-T2PV2-40-1000 Wallis photovoltaic surge protector
Wiring diagram of a WSP-T2PV2-40-1000 photovoltaic surge protector

The WSP-T2PV2/40/1000 is a surge arrester type 2, according to BS EN 61643-11. photovoltaic surge arrester. This complete device consists of a base part and pluggable modules. These arresters are recommended for use in the Lightning Protection Zones Concept at the boundaries of LPZ 1-2 (according to IEC 1312-1 and BS EN 62305) for equipotential bonding of positive and negative busbars of photovoltaic systems and elimination of transient overvoltages that originate during atmospheric discharges or switching processes.

The failure indication of these disconnectors is partly visual (discoloration of the signal field) and partly remote monitoring by potential free switching contacts.

Features and Benefits:

  • Simple to install.
  • A response time (tA) of <25ns.
  • Minimum life of 100,000 hours.
Max. Continuous Operating Voltage DC (Uc)Short-Circuit Withstand Capability (Iscwpv)Max. Discharge Current (8/20) (Imax)Nominal Impulse Discharge Current (8/20) (In)Voltage Protection Level at In (Up)Part Number
Max. Continuous Operating Voltage DC (Uc)1050V DCShort-Circuit Withstand Capability (Iscwpv)100kAMax. Discharge Current (8/20) (Imax)40kANominal Impulse Discharge Current (8/20) (In)15kAVoltage Protection Level at In (Up)<3.8kVPart NumberWSP-T2PV2/40/1000

.
