Universal Beam Clamp

In-situ image of copper tape and stranded cable connected to an RSJ using a universal beam clampDimensional drawing of a universal beam clamp

This Universal Beam Clamp is a unique product as it is designed to bond 25x3mm copper tape, 50sqmm and 70sqmm stranded cable as well as 8mm solid circular conductor to steel beams and RSJ’s of up to 15mm thick.

No other product on the market offers this range of alternatives when bonding to steel beams and RSJ’s.

The universal beam clamps robust design allows multiple connections without compromise to the strength or quality.

The A. N. Wallis universal beam clamp is manufactured from high copper alloy and comes with stainless steel bolts.

Conductor Range (sqmm)Conductor Size (mm)L (mm)W (mm)H (mm)H1 (mm)Unit Weight (kg)Pack QuantityPart Number
Conductor Range (sqmm)50 - 70Conductor Size (mm)25 x 3L (mm)80W (mm)43H (mm)35H1 (mm)18Unit Weight (kg)0.39Pack Quantity8Part NumberUBC 001

Material: High Copper Alloy with Stainless Steel Bolts
