Concrete Earth Inspection Housing

An image of 2 Wallis concrete earth inspection housing units
In-situ image of a concrete earth inspection pit installed into the ground over an earth rod and copper tapeDimensional drawing of a concrete earth inspection pit

The Wallis concrete earth inspection pits are load rated to 4,500kg, which makes these earth pits suitable for most types of earthing and lightning protection installations.

There are two different types of lids that can be purchased with the concrete earth inspection unit. One with a central lifting eye for industrial applications. The other with a unique plain lid non-trip surface, ideal for public and pedestrian areas such as shopping arcades, supermarket forecourts, Mosques, cinemas etc. wherever trip hazards are a potential problem.

The base is designed to accept a diagonal earth bar with 5 or 7 terminations (EBC05 and EBC07). These are used when multiple connections to the earth rod are required.

If an alternative high load inspection earth pit is required, the Heavy-Duty Inspection Pit (EPP001W) is recommended as this product is ideal for areas where high loads or small wheel vehicles are used, rated up to 6,000kg, lockable and available with a black or grey lid.

The entire range of A. N. Wallis earth pits can be viewed here.

Lid TypeL (mm)W (mm)H (mm)Unit Weight (kg)Part Number
Lid TypeNon Trip Plain LidL (mm)315W (mm)315H (mm)170Unit Weight (kg)24Part NumberERH 01W
Lid TypeCentral Lifting EyeL (mm)315W (mm)315H (mm)170Unit Weight (kg)24Part NumberERH 02W
Lid TypeCentral Lifting EyeL (mm)315W (mm)315H (mm)185Unit Weight (kg)26Part NumberERH 07W
Lid TypeNon Trip Plain LidL (mm)450W (mm)450H (mm)450Unit Weight (kg)102Part NumberERH 450

Material: Concrete

Tested: BS EN 62561-5
