Earth Rod to Cable G Clamps

These earth clamps are referred to as ‘G’ clamps and are used for joining earth rods to different sizes of stranded copper conductor. The clamps have a high resistance to corrosion and are mechanically strong to ensure a lasting connection.

The ‘G’ clamps are manufactured from High Copper Alloy and come with an M10 x 25mm phosphor bronze set screw.

Earth Rod Shank Ø (mm)	Conductor Range (sqmm)	L (mm)	W (mm)	H (mm)	Unit Weight (kg)	Part Number
Earth Rod Shank Ø (mm)9.5	Conductor Range (sqmm)6 - 35	L (mm)30	W (mm)20	H (mm)15	Unit Weight (kg)0.05	Part NumberERR 1035	Quantity
Earth Rod Shank Ø (mm)12.7	Conductor Range (sqmm)6 - 35	L (mm)36	W (mm)28	H (mm)18	Unit Weight (kg)0.07	Part NumberERR 1635	Quantity
Earth Rod Shank Ø (mm)12.7	Conductor Range (sqmm)35 - 70	L (mm)41	W (mm)26	H (mm)20	Unit Weight (kg)0.08	Part NumberERR 1670	Quantity
Earth Rod Shank Ø (mm)14.2	Conductor Range (sqmm)6 - 16	L (mm)36	W (mm)28	H (mm)18	Unit Weight (kg)0.07	Part NumberERR1635	Quantity
Earth Rod Shank Ø (mm)14.2	Conductor Range (sqmm)16 - 70	L (mm)41	W (mm)26	H (mm)20	Unit Weight (kg)0.08	Part NumberERR1670	Quantity
Earth Rod Shank Ø (mm)14.2	Conductor Range (sqmm)35 - 150	L (mm)48	W (mm)30	H (mm)18	Unit Weight (kg)0.09	Part NumberERR 2095	Quantity
Earth Rod Shank Ø (mm)15.0	Conductor Range (sqmm)6 - 16	L (mm)36	W (mm)28	H (mm)18	Unit Weight (kg)0.07	Part NumberERR 1635.	Quantity
Earth Rod Shank Ø (mm)15.0	Conductor Range (sqmm)16 - 70	L (mm)41	W (mm)26	H (mm)20	Unit Weight (kg)0.08	Part NumberERR 1670.	Quantity
Earth Rod Shank Ø (mm)15.0	Conductor Range (sqmm)25 - 150	L (mm)48	W (mm)30	H (mm)18	Unit Weight (kg)0.09	Part NumberERR 2095.	Quantity
Earth Rod Shank Ø (mm)16.0	Conductor Range (sqmm)6 - 70	L (mm)41	W (mm)26	H (mm)20	Unit Weight (kg)0.08	Part NumberERR1670.	Quantity
Earth Rod Shank Ø (mm)16.0	Conductor Range (sqmm)16 - 150	L (mm)48	W (mm)30	H (mm)18	Unit Weight (kg)0.09	Part NumberERR2095.	Quantity
Earth Rod Shank Ø (mm)17.2	Conductor Range (sqmm)16 - 120	L (mm)48	W (mm)30	H (mm)18	Unit Weight (kg)0.09	Part NumberERR 2095..	Quantity
Earth Rod Shank Ø (mm)20.0	Conductor Range (sqmm)16 -95	L (mm)48	W (mm)30	H (mm)18	Unit Weight (kg)0.09	Part NumberERR2095..	Quantity

Material: High Copper Alloy with M10 x 25mm Phosphor Bronze Set Screw.

Tested: BS EN 62561-1 Class H

Tightening Torque: 12 Nm; ERR 1635 13 Nm; ERR 2095 20 Nm
