Free-Standing Air Terminals

An image of our discontinued free standing air terminal range

*DISCONTINUED*

Please contact our sales office on +44 (0) 115 927 1721 for further details on our new range of Free-Standing Air Terminals

A range of free-standing lightning interception terminals for the protection of roof-mounted equipment on surfaces where no penetration of the roof structure for anchoring is allowed.

A multi-component, stackable system with screw retention to achieve protection heights of up to 12m.

The free-standing air terminal system is designed to withstand wind speeds of up to 118mph (190kmh). We recommend that all concrete bases (that are installed in conjunction with the free-standing air terminals) are installed using the protective roof pads (PRP 001).

Terminal Height (M)Components (M)Unit Weight (kg)Part Number
Terminal Height (M)3.0Components (M)Two-Piece: 1.5 + 1.5Unit Weight (kg)5.00Part NumberATF 030
Terminal Height (M)3.5Components (M)Two-Piece: 2.0 + 1.5Unit Weight (kg)5.50Part NumberATF 035
Terminal Height (M)4.0Components (M)Two-Piece: 2.5 + 1.5Unit Weight (kg)7.00Part NumberATF 040
Terminal Height (M)4.5Components (M)Two-Piece: 3.5 + 1.0Unit Weight (kg)9.20Part NumberATF 045
Terminal Height (M)5.0Components (M)Two-Piece: 3.5 + 1.5Unit Weight (kg)10.00Part NumberATF 050
Terminal Height (M)5.5Components (M)Two-Piece: 4.0 + 1.5Unit Weight (kg)10.60Part NumberATF 055
Terminal Height (M)6.0Components (M)Three-Piece: 2.0 + 2.0 + 2.0Unit Weight (kg)18.00Part NumberATF 060
Terminal Height (M)6.5Components (M)Three-Piece: 2.5 + 2.0 + 2.0Unit Weight (kg)21.20Part NumberATF 065
Terminal Height (M)7.0Components (M)Three-Piece: 3.0 + 2.0 + 2.0Unit Weight (kg)23.50Part NumberATF 070
Terminal Height (M)7.5Components (M)Three-Piece: 3.5 + 2.0 + 2.0Unit Weight (kg)26.00Part NumberATF 075
Terminal Height (M)8.0Components (M)Three-Piece: 4.0 + 2.0 + 2.0Unit Weight (kg)28.70Part NumberATF 080
Terminal Height (M)9.0Components (M)Three-Piece: 4.0 + 2.5 + 2.5Unit Weight (kg)30.50Part NumberATF 090
Terminal Height (M)10.0Components (M)Three-Piece: 5.0 + 2.5 + 2.5Unit Weight (kg)35.50Part NumberATF 010
Terminal Height (M)11.0Components (M)Three-Piece: 5.0 + 3.5 + 2.5Unit Weight (kg)37.80Part NumberATF 011
Terminal Height (M)12.0Components (M)Three-Piece: 6.0 + 3.5 + 2.5Unit Weight (kg)42.90Part NumberATF 012

Material: Stainless Steel with Aluminium Tip.
