Solid Copper Earth Rods

These earth rods are designed for use where extremely high corrosion resistance and exceptionally long life are required. Solid copper earth rods are produced from solid copper bar and are internally threaded for jointing. When deep driving a solid copper earth rod the usual practice is to insert the rod into a bore hole and backfill with either Low-Resistance Earthing Compound or Bentonite.

Shank D mmL (mm)Thread SizeL1 (mm)Unit Weight (kg)Pack QuantityPart Number
Shank D mm15L (mm)1200Thread SizeM10L1 (mm)20Unit Weight (kg)1.88Pack Quantity5Part NumberERC 112
Shank D mm16L (mm)1500Thread SizeM10L1 (mm)20Unit Weight (kg)2.66Pack Quantity5Part NumberERC 115
Shank D mm16L (mm)1800Thread SizeM10L1 (mm)20Unit Weight (kg)3.20Pack Quantity5Part NumberERC 118
Shank D mm16L (mm)2400Thread SizeM10L1 (mm)20Unit Weight (kg)4.28Pack Quantity5Part NumberERC 124
Shank D mm16L (mm)3000Thread SizeM10L1 (mm)20Unit Weight (kg)5.36Pack Quantity5Part NumberERC 130
Shank D mm20L (mm)1200Thread SizeM10L1 (mm)20Unit Weight (kg)3.34Pack Quantity5Part NumberERC 212
Shank D mm20L (mm)1500Thread SizeM10L1 (mm)20Unit Weight (kg)4.18Pack Quantity5Part NumberERC 215
Shank D mm20L (mm)1800Thread SizeM10L1 (mm)20Unit Weight (kg)5.03Pack Quantity5Part NumberERC 218
Shank D mm20L (mm)2400Thread SizeM10L1 (mm)20Unit Weight (kg)6.71Pack Quantity5Part NumberERC 224
Shank D mm20L (mm)2500Thread SizeM10L1 (mm)20Unit Weight (kg)7.00Pack Quantity5Part NumberERC 225
Shank D mm20L (mm)3000Thread SizeM10L1 (mm)20Unit Weight (kg)8.40Pack Quantity5Part NumberERC 230
Shank D mm25L (mm)1000Thread SizeM12L1 (mm)25Unit Weight (kg)4.37Pack Quantity1Part NumberERC 310
Shank D mm25L (mm)1200Thread SizeM12L1 (mm)25Unit Weight (kg)5.25Pack Quantity1Part NumberERC 312
Shank D mm25L (mm)1500Thread SizeM12L1 (mm)25Unit Weight (kg)6.54Pack Quantity1Part NumberERC 315
Shank D mm25L (mm)1800Thread SizeM12L1 (mm)25Unit Weight (kg)7.86Pack Quantity1Part NumberERC 318
Shank D mm25L (mm)2000Thread SizeM12L1 (mm)25Unit Weight (kg)8.73Pack Quantity1Part NumberERC 320
Shank D mm25L (mm)2400Thread SizeM12L1 (mm)25Unit Weight (kg)10.50Pack Quantity1Part NumberERC 324
Shank D mm25L (mm)2500Thread SizeM12L1 (mm)25Unit Weight (kg)10.90Pack Quantity1Part NumberERC 325
Shank D mm25L (mm)3000Thread SizeM12L1 (mm)25Unit Weight (kg)13.10Pack Quantity1Part NumberERC 330
Shank D mm25L (mm)3600Thread SizeM12L1 (mm)25Unit Weight (kg)15.90Pack Quantity1Part NumberERC 336

Material: Copper to BS EN 13601

Tested: BS EN 62561-2
